The OpenAPI Discriminator is Redundant & Confusing
A quick look at why OpenAPI's "discriminator" keyword is an outdated concept that you can probably skip worrying about learning.
If you’ve worked with OpenAPI v3.x, you might have come across the discriminator
field in schemas. It’s often used alongside oneOf
, anyOf
, or allOf
when you’ve got different variations of a type—polymorphism, essentially. At first glance, it seems pretty handy; it’s meant to help you figure out which specific schema to use when certain values are present, but JSON Schema can handle this out of the box without using the poorly supported OpenAPI-only keyword discriminator
.
Let’s dive into why the discriminator
is probably an outdated concept that you can skip struggling to learn, by looking through a couple of examples to show how things can be done without it.
What’s the Discriminator All About, Anyway?
In OpenAPI, the discriminator
is a field that helps you figure out which schema you’re dealing with when you’ve got multiple possibilities. It’s kind of like a switch that tells you which specific object or type your payload is going to conform to, using a specific field in the input—often something like a type
field.
components:
schemas:
Animal:
oneOf:
- $ref: '#/components/schemas/Dog'
- $ref: '#/components/schemas/Cat'
discriminator:
propertyName: type
mapping:
dog: '#/components/schemas/Dog'
cat: '#/components/schemas/Cat'
Dog:
type: object
properties:
type:
type: string
const: dog
barkVolume:
type: integer
Cat:
type: object
properties:
type:
type: string
const: cat
whiskerLength:
type: integer
Here, we’ve got an Animal
schema that could either be a Dog
or a Cat
. The discriminator
is saying “look at the type
field in the payload to figure out whether this is a Dog
or a Cat
.”
If the type
field says dog
, then OpenAPI knows to check against the Dog
schema, and if it says cat
, it’ll check against the Cat
schema.
Perhaps you send a payload like this:
{
"type": "dog",
"barkVolume": 10
}
It will use the Dog
schema.
But Here’s the Thing...
The discriminator
doesn’t actually do anything in terms of validation. It’s only there as a hint to speed things up for tooling like code generation tools, so they can quickly figure out which schema to use in certain situations. Whether or not you have the discriminator
, the validation will still work, documentation can show available options, mocking tools can generate a sample response by picking one of the subschemas, everything will work just fine.
Without it, you can still rely on the natural shape of the data. This particular JSON instance has type: dog
in there, and that acts as the switch in the oneOf by matching against the const: dog
in the subschema.
components:
schemas:
Animal:
oneOf:
- $ref: '#/components/schemas/Dog'
- $ref: '#/components/schemas/Cat'
Dog:
type: object
properties:
type:
type: string
const: dog
barkVolume:
type: integer
Cat:
type: object
properties:
type:
type: string
const: cat
whiskerLength:
type: integer
If you have a property to act as a switch then you're fine. If you don't have one then discriminator could never have worked, because it's fairly rigid like that. The oneOf approach does not need a single specific field to provide a mapping
, it can use any combination of values, so even without the type
field you could have different required properties on Dog
objects (like barkVolume
), and Cat
objects (like whiskerLength
), and that would be enough to select a scheme.
Fixing Examples of Discriminator
Here's an example from another documentation provider who have an example of discriminator
to help pick between different powerSources
for a vehicle.
schema:
discriminator:
propertyName: powerSource
mapping:
electricity: "#/components/schemas/ElectricVehicle"
gasoline: "#/components/schemas/FueledVehicle"
human-energy: "#/components/schemas/PedaledVehicle"
anyOf:
- $ref: "#/components/schemas/ElectricVehicle"
- $ref: "#/components/schemas/FueledVehicle"
- $ref: "#/components/schemas/PedaledVehicle"
components:
ElectricVehicle:
type: object
properties:
powerSource:
description: How is the vehicle powered.
type: string
example: electricity
...
We could just delete that whole discriminator
object, and change example: electricity
to const: electricity
.
schema:
anyOf:
- $ref: "#/components/schemas/ElectricVehicle"
- $ref: "#/components/schemas/FueledVehicle"
- $ref: "#/components/schemas/PedaledVehicle"
This will actually work better, and give more meaningful validation on powerSource
.
Picking Between Schemas
I think people got a bit hooked on the idea of discriminators because it's "the way to do polymorphism in OpenAPI". That may have been true in OpenAPI v2.0, but OpenAPI v3.0 got the anyOf
and oneOf
keywords which handle that.
Some tools perpetuate the reliance on discriminator
by pushing users to use them in order to show selectors allowing users to switch between different oneOf
and anyOf
subschemas.
Modern OpenAPI documentation does not need to do this. For example, Bump.sh will take the end of each of the $ref
, turning "#/components/schemas/ElectricVehicle"
into ElectricVehicle
and "#/components/schemas/PedaledVehicle"
into PedaledVehicle
in the interface.
If you’d like more human-readable names you can add the title
keyword to each of those referenced schemas.
components:
ElectricVehicle:
title: Electric Vehicle
type: object
properties:
powerSource:
description: How is the vehicle powered.
type: string
const: electricity
...
That will then update the selectors to use the provided name instead of the generated one.
Between oneOf
, anyOf
, and title
, most documentation tooling can create brilliant interactive selectors without forcing people to write out each possible mapping.
Wrapping Up
The discriminator
in OpenAPI v3.x is less useful than it might seem at first. It doesn’t affect whether a payload is valid, doesn't help with documentation, mocking, or anything much else.
The main reason for using it is to help tools like code generators and their resulting output code, which need to know which schema to pick quickly. In that case, sure, add these optimization shortcuts to your OpenAPI with discriminator
speed things up, but in most cases you’re better off keeping things simple and letting the data itself decide which schema to use.
